Orion-Tr隔离式智能充电器
Orion-Tr智能直流-直流充电器是一款内置蓝牙的专业直流-直流自适应三段式充电器。
适用于汽车或船舶上的双电池系统，其中（智能）交流发电机和启动电池用来为动力电池充电。该装置可通过蓝牙进行监控和编程，还可通过远程开关进行远程控制，并具有引擎运行检测机制。
Orion-Tr智能充电器可用于12V, 24V或48V系统，适用于铅酸电池和锂电池。型号可达400W，可并联无限多个电池组，增加输出功率。
最高可适用于55°C的高温和最高40°C的全额定输出。
Models:
12 / 24 / 48 Volt
Year warranty
World-wide support
关于此
产品
Orion-Tr智能直流-直流充电器是一款内置蓝牙的专业直流-直流自适应三段式充电器。
适用于汽车或船舶上的双电池系统，其中（智能）交流发电机和启动电池用来为动力电池充电。该装置可通过蓝牙进行监控和编程，还可通过远程开关进行远程控制，并具有引擎运行检测机制。
Orion-Tr智能充电器可用于12V, 24V或48V系统，适用于铅酸电池和锂电池。型号可达400W，可并联无限多个电池组，增加输出功率。
最高可适用于55°C的高温和最高40°C的全额定输出。
